xEncoder Sensor H9730 1930 – Type A and Type B
Product Overview
The H9730 1930 encoder sensor delivers stable, low-noise decoding for large format printers. Designed for high reliability and clean signal output, it supports precise carriage motion control and reduces banding caused by jitter or read errors.
Key Features
- Clean, stable decoding with optimized optical path.
- Robust PCB with reinforced solder joints for long service life.
- 60 cm fixed cable option for quick installation and tidy routing.
- Available in Type A / Type B layouts to match different carriages.
- Compatible with 150 LPI to 180 LPI grating strips commonly used in large format systems.
Technical Specifications
| Model | H9730 1930 |
| Signal Output | Quadrature A/B channel |
| Recommended Grating | 150–180 LPI strip |
| Cable Length | 60 cm fixed |
| Application | Large format inkjet carriage position sensing |
Type Comparison
| Type | Board Layout | Typical Use |
|---|---|---|
| Type A | Sensor sits closer to the connector side; suitable for carriages with shorter mounting standoffs or inward cable routing. | Carriages requiring compact footprint and front-side cable exit. |
| Type B | Sensor offset to the opposite side; provides extra clearance for screws and shields; cable exits outward. | Carriages with wider brackets or rear-side cable exit. |
Package Includes
- H9730 1930 encoder sensor × 1
- 60 cm signal cable × 1
- Basic mounting screws (if applicable)
Installation Tips
- Power off the machine and remove the original sensor.
- Mount the new board so the optical window aligns with the grating strip centerline.
- Keep 0.3–0.6 mm gap between sensor and strip; ensure strip is clean and tensioned.
- Route the cable away from high-voltage lines and RF sources.
- Perform carriage homing and test print to verify smooth motion.
Notes: Choose Type A or Type B according to your carriage layout. If you are unsure, provide a photo of the original board and cable orientation for confirmation.
